| Features
> Frequency Range: 6.5-18.0 GHz > Gain: LB-65180-23 Series: 23 dBi Typ. LB-65180-25 Series: 25 dBi Typ. > Linear Polarization > Output: WRD650 or Coaxial > Cross Pol. Isolation: 40 dB Typ. > VSWR: 1.25:1 Typ. > High Power 500 W version: LB-65180-23-C-HNF LB-65180-25-C-HNF > Special Version For Outdoor Use with Radome & Special Painting Anti Dust, Water Proof > Far Field Calibration Data with Extra Fee > Optional Accessories, like Tripod, Mounting Bracket , Cable, Carrying Case etc Applications: > EMC Applications and Systems > UWB Communication Systems > Measurement Systems > Other Applications |
Advantages
A-INFO, a leading manufacturer and supplier of RF, microwave, and millimeter wave products, is proud to introduce the Multi Octave Horn Antennas, LB-65180-23 and LB-65180-25 series. These products have low VSWR and can cover a frequency range of 6.5 – 18GHz, allowing them to cover popular EMC Bands. These items are ideal for a variety of applications such as testing, EMC Applications, measurements, and other applications. Additionally, A-INFO can provide specific horn antennas, customized according to the customer’s requirements and needs. A-INFO also provides a variety of other antennas as well, so please look at them all to see if one fits your needs.
|
| Model | Freq.(GHz) | Polarization | Gain, Typ.
(dB) |
Power Handling, Max.
(W CW) |
Output Type |
| LB-65180-23-A | 6.5-18 | Linear | 23 | 2600 | WRD650 Flange |
| LB-65180-23-C-SF | 6.5-18 | Linear | 23 | 50 | SMA-Female |
| LB-65180-23-C-ESF | 6.5-18 | Linear | 23 | 50 | Endlaunch SMA-Female |
| LB-65180-23-C-NF | 6.5-18 | Linear | 23 | 150 | N-Female |
| LB-65180-23-C-ENF | 6.5-18 | Linear | 23 | 150 | Endlaunch N-Female |
| LB-65180-23-C-HNF | 6.5-18 | Linear | 23 | 500 | N-Female |
| LB-65180-25-A | 6.5-18 | Linear | 25 | 2600 | WRD650 Flange |
| LB-65180-25-C-SF | 6.5-18 | Linear | 25 | 50 | SMA-Female |
| LB-65180-25-C-ESF | 6.5-18 | Linear | 25 | 50 | Endlaunch SMA-Female |
| LB-65180-25-C-NF | 6.5-18 | Linear | 25 | 150 | N-Female |
| LB-65180-25-C-ENF | 6.5-18 | Linear | 25 | 150 | Endlaunch N-Female |
| LB-65180-25-C-HNF | 6.5-18 | Linear | 25 | 500 | N-Female |
