> Frequency Range: 32-38GHz

> Insertion Loss: 0.2 dB Max.

> VSWR: 1.15:1 Max.

> Isolation: 20 dB Min.

> Amplitude Balance: ±0.5 dB Max.

> Phase Balance: ±2° Max.

> Average Power: 110 W CW

> Peak Power: 4 KW

> Flange: FBP320(UBR320)

Applications

> Antenna Systems

> Microwave Radio

> Measurement Systems

> Other Applications

A-INFO, a leading manufacturer and supplier of RF, microwave, and millimeter wave products, is proud to introduce series Waveguide Hybrid Coupler 28WXSCA-3-16G_Cu, 28WYSCA-3-16G_Cu, and 28WZSCA-3-16G_Cu. It is a short slot 90 degree hybrid coupler that delivers a 3dB nominal coupling level. The A-INFO’s waveguide hybrid coupler is manufactured with a high precision machining process to ensure high quality and ruggedness. They are ideal for radar antenna systems, laboratory test set-ups, microwave radio, satellite communications, and other applications requiring low insertion loss, and low return loss. Different flange types may be available in stock, and please contact us to inquire further.

A-INFO can provide various other waveguide components, antennas, customizations of specific gain horn antennas, and a variety of components that can fit your project need. Check out A-INFO’s website to view all of the products that A-INFO can offer you. All of our products are high quality and can work with a variety of projects and systems. All of A-INFO’s products are guaranteed with a warranty as outlined in our Terms and Conditions.

Contact us if you have any additional questions and inquiries to see if any of our products are right for your project needs.
